AntiGuide: WolPoBoxArduinoCloud

#include <Arduino.h>
#include <EtherCard.h>
//#include <IPAddress.h>
#include <MemoryFree.h>

// ethernet interface mac address, must be unique on the LAN
#define VERSION "WOWlanCloud 20140102-1805"
#define URL "/index.php?action=get&id=zorglub"
#define WEBSITE "wolpobox.logsm.net"
#define PERIODEMS 5000
#define  WOLLISTENPORT 9
#define  WOLTARGETPORT 9
#define  WOLOUTPORT 100
#define true 1
#define false 0
#define DEBUG false   // true for debugging
#define TRACE true    //some progree info.
#define CLOUD true
#define SERVER true
#define PROXY true
#define LBUF 600
char website[] PROGMEM = WEBSITE;
char url[] PROGMEM = URL;
static byte mymac[] = { 0x00,0x16,0xA5,0x76,0x19,0x3A  };
static byte lowip= 255;  // left part by Dhcp 255 if no!

static uint32_t timer;

static byte broadcast[4] = {255,255,255,255} ; //{255,255,255,255};
static int n=0;  // count http requests
static int ok=true;  // global abandon
static int lenquoi;
static  int termine;  // 1 when found
static  int eq;
static int iii;
static    int pv;
static    int ipv;

// byte mac[6] ;
byte key[10];
char magic[102];
char alphabet[23] /*PROGMEM*/ ="0123456789ABCDEFabcdef";
char hexamac[100]="";
byte Ethernet::buffer[LBUF];      //??????
BufferFiller bfill;                     //???????
static int udpon=0;


void setup () {
//   pinMode(13, OUTPUT);
  Serial.begin(9600);
  Serial.println("andiamo ");
  Serial.println(VERSION);
  Serial.print("Options: Debug, Trace, Cloud, Server, Proxy:");
  Serial.print (DEBUG);
  Serial.print (TRACE);
  Serial.print (CLOUD);
  Serial.print (SERVER);
  Serial.println (PROXY);
    Serial.print("freeMemory()=");
    Serial.println(freeMemory());

  Serial.print("Ethernet Controller: ");
  if (ether.begin(sizeof Ethernet::buffer, mymac,10) == 0) {
    ok=false;
    Serial.println( "Access Failed.");
  } else Serial.println("Ok.");
  //  ether.staticSetup(myip);

if (ok) {
     Serial.print("Dhcp: ");
     if (!ether.dhcpSetup()) {
       Serial.println("failed.");
       ok=false;
     } else Serial.println("Ok.");
  }
  if (ok){
     if (lowip<255) ether.myip[3]=lowip;
     ether.printIp("IP:  ", ether.myip);
     ether.printIp("GW:  ", ether.gwip);
     ether.printIp("DNS: ", ether.dnsip);

  if (CLOUD){
      if (!ether.dnsLookup(website)) {
             Serial.println("DNS failed");
             ok=false;
      }
      if (ok) {
          ether.printIp("SRV: ", ether.hisip);
      }
  }

  }
  //register udpSerialPrint() to port 1337
  if (ok && PROXY) {
     ether.udpServerListenOnPort(&udpReceivedCallback, WOLLISTENPORT);
     Serial.print("listen on port: ");
     Serial.println(WOLLISTENPORT);
  }
}

void getvalue(word off,word len,char retour[],int lenret,char pin[]){
  lenquoi=strlen(pin);

//  search for pin:
  termine=false;  // 1 when found pin
  eq;
  iii=-1;
  while (!termine) {
           eq=0;
           iii=iii+1;
           if (iii==len) termine=1;
           while ((eq<lenquoi) && (Ethernet::buffer [off+iii+eq]==pin[eq])){
                if (eq==lenquoi-1 )  termine=true;
                eq=eq+1;
        }
  }
  // Serial.println("");
  if (termine) {
    pv=false;
    ipv=0;
    //Serial.print("reponse=");
    while (!pv && iii+eq+1+ipv<len  && ipv<lenret ) {
         retour[ipv]=Ethernet::buffer [off+iii+eq+ipv];
         if (retour[ipv]==';') {
              retour[ipv]=0;
              pv=true;
         }


         ipv=ipv+1;
         }
    }
if (!termine || !pv) {
      Serial.println ("no colon found");
      ok=false;
  }
}


// called when the client request is complete
static void my_callback (byte status, word off, word len) {
  if (DEBUG) Serial.println(">>>");
  Ethernet::buffer[off+len] = 0;
    if (DEBUG) for (int j=0;j<len;j=j+1) Serial.print((char ) Ethernet::buffer[off+j]);
 // check print full packet
   getvalue(off,len,hexamac,100,"mac:");
  if (strlen(hexamac)==0) return;
  getvalue(off,len,hexamac,100,"ip:");
  getvalue(off,len,hexamac,100,"id:");
  getvalue(off,len,hexamac,100,"token:");
  getvalue(off,len,hexamac,100,"mac:");
   if (TRACE) {
       Serial.print("Cloud: mac:");
       Serial.println(hexamac);
   }
   buildmagic();
   sendmagic(magic,102);
}

//callback that echo received packet (magic!)
void udpReceivedCallback(word port, byte ip[4], const char *data, word len) {
  if (!udpon) {  // protect again re-entrance'
    udpon=true;
    if (DEBUG){
       Serial.println(" Raw: ");
      Serial.println(data);
    }
    if (TRACE) Serial.println ("udp packet forwarded as broadcast");
    sendmagic((char *) data,len);
    if (DEBUG) Serial.println(" done");

    udpon=false;
  }
}




static word hP() {
  n=n+1; // compte les appels à homePage

  long t = millis() / 1000;
  word h = t / 3600;
  byte m = (t / 60) % 60;
  byte s = t % 60;
  bfill = ether.tcpOffset();
  bfill.emit_p(PSTR(                                 //???????
    "HTTP/1.0 200 OK\r\n"
    "Content-Type: text/html\r\n"
    "Pragma: no-cache\r\n"
    "\r\n"
//    "<meta http-equiv='refresh' content='1'/>"
    "<title>Po server</title>"
    "<h1>$D$D:$D$D:$D$D</h1> n= $D"),
      h/10, h%10, m/10, m%10, s/10, s%10,n);                //???????
  return bfill.position();                                           //???????
}

int h2d(char h){
        char* ih=  strchr(alphabet,h);
        char* i0= strchr(alphabet,'0');
        int ici=ih-i0;
        if (ici>15) ici=ici-6;
      return ici;
}

void buildmagic (){
    if (DEBUG)    Serial.print("build magic mac:");
       for (int repe=0;repe<6;repe=repe+1) magic[repe]=255;
       for (int p=0;p<6;p=p+1){
         byte g=h2d(hexamac[2*p]);
         byte d=h2d(hexamac[2*p+1]);
         int h2=g*16+d;
         magic[6+p]=h2;
         for (int repe=1;repe<16;repe=repe+1){
            magic[6+6*repe+p]=magic[6+p];
         }
       }

}

void sendmagic(char* magic,int len){
   if (DEBUG) Serial.println("sendmagic");
   if (DEBUG) Serial.println(magic);
     ether.sendUdp(magic, len, WOLOUTPORT, broadcast, WOLTARGETPORT);
}

void loop () {

   if (ok==1 && PROXY) {
     // nothing
   }

   if (CLOUD)        ether.packetLoop(ether.packetReceive());

   if (ok==1 && CLOUD) {

     if (millis() > timer) {
       timer = millis() + PERIODEMS;
        ether.browseUrl(PSTR(URL) , "", website, my_callback);
    }  // timer

   }  // end cloud

   if (ok==1 && SERVER){
      word len = ether.packetReceive();
      word pos = ether.packetLoop(len);
     if (pos>0)  {// check if valid tcp data is received
     getvalue(pos,len-pos,hexamac,100,"mac:");
           ether.httpServerReply(hP()); // send web page data

     if (hexamac != "") {
       if (TRACE) {
            Serial.print("Http: ");
            Serial.println(hexamac);
       }
        buildmagic();
        sendmagic(magic,102);
     }

   }
   }
}
